Agitador Mecânico – Eurostar 60 Control

O pacote inclui:
EUROSTAR 60 control.
Suporte telescópico R 2723.
Mufa R 271.
Agitador com propulsor R 1345,

4 lâminas Braçadeira de amarra RH 5

Dados técnicos
Deviation of speed measurement n > 300rpm: 1±%
Deviation of speed measurement n < 300rpm: 3±rpm
Width: 86mm
Power input: 176W
Time setting max.: 6000min
Hollow shaft, inner diameter: 11mm
Extension arm length: 220mm
Extension arm diameter: 16mm
Chuck range max. diameter: 10mm
Chuck range min. diameter: 0.5mm
Setting accuracy speed: 1±rpm
Temperature measurement resolution: 0.1K
Temperature measuring range max.: +350°C
Accuracy of temperature measurement: ±0.5 + tolerance PT1000 (DIN IEC 751 Class A)K
Limit deviation temperature sensor: ≤ ± (0.15 + 0.002xITI)K
Torque max. at stirring shaft: 60Ncm
Output max. at stirring shaft: 126W
Nominal torque: 0.6Nm
Motor rating input: 168W
Voltage: 230/115/100V
Motor rating output: 131W
Stirring quantity max. per stirring position (H2O): 40l
Viscosity max.: 50000mPas
deviation of torque measurement I: 6±Ncm
Speed min.: 0/30rpm
communication distance (depend onbuilding) max.: 150m
Depth: 230mm
Height: 267mm
Time setting min.: 1min
Speed max.: 2000rpm
Temperature display: yes
Speed control: electronic, stepless
Connection for ext. temperature sensor: PT1000
Reversible direction of rotation: no
housing material: alu-cast coating / thermoplastic polymer
Motor principle: Brushless DC
Fastening on stand: extension arm
Hollow shaft (push-through – when stopped): yes
RS 232 interface: yes
Timer: yes
USB interface: yes
Protection class according to DIN EN 60529: IP 40
Stirring element fastening: chuck
clean room qualified: no
explosion proofed: no
Permissible relative humidity: 80%
Permissible ambient temperature max.: 40°C
Frequency: -
